Answer
May 12, 2025 - 07:19 AM
Do you have the same question? Follow this Question
May 12, 2025 - 07:19 AM
We’ve provided several answers to questions related to Blum 21" TANDEM plus BLUMOTION 563F Undermount Drawer Slide Blum 563F5330B , see some other helpful Q&A related to this product.
Question: What is the purpose of the elongated holes in the drawer slide?
Answer: The elongated holes in the 563f blum drawer slides are designed for depth adjustment. This feature allows for easy alignment and installation, ensuring the drawer fits perfectly within the cabinet.
Question: What series does this drawer slide belong to?
Answer: This drawer slide is part of the TANDEM plus BLUMOTION 563F series. This series is designed for using 3/4" drawer box material.
Question: What is the shank height for the cabinet profile of the 21" TANDEM drawer slide?
Answer: The shank height for the cabinet profile of the 21" Blum 563H is 47.5mm or 1.87". This measurement is important for fitting the slide into the cabinet space and ensuring proper alignment with the drawer.
Question: Will these work with Blum T51.170-01.04 locking devices?
Answer: No. The T51.1700 is specifically for the old 562/568 series.
Question: How much will these sag fully extended and loaded at 125lbs?
Answer: Unfortunately, we can not provide you with a correct answer to your question. For the correct answer. Please contact Blum customer service at 800-438-6788.
Question: Is the drawer box thickness compatible with the Blum 12" TANDEM plus BLUMOTION undermount slides?
Answer: The blum 12 undermount drawer slides are compatible with a drawer box thickness of 3/4 inch. This standard thickness allows for a snug and secure fit, ensuring optimal performance.
Question: How much do you subtract for Blum F series undermount drawer slides?
Answer: When using 3/4" material your box should be 7/16" narrower than the cabinet opening.
For for example, a 21" opening width and a 3/4" thick drawer, 21" minus 7/16" = 20-9/16" drawer width
Question: What static load capacity does the slide have for heavy duty runners?
Answer: The static load capacity for heavy duty runners is 170 lbs. This ensures that even heavier loads can be supported, enhancing the slide's versatility and range of use.
Question: What series is the slide part of?
Answer: The slide is part of the MOVENTO series. The MOVENTO series is known for its smooth running action and advanced engineering, providing superior performance and reliability.
Question: What is the product type?
Answer: The product is an undermount drawer slide. This type of slide is mounted beneath the drawer, providing a clean look and allowing for smooth, unobstructed movement.
Question: which rear brackets go with these?
Answer: The rear bracket that is needed is our part # 11361014.
Question: is the measurement of the slide actual or is it for an 18'deep cabinet
Answer: Undermount slides are designed for drawer boxes with specific allowances. 18" slides require an 18" drawer box among other allowances. 18" slides are generally used in 21" deep cabinets.
